F4BMX-1/2 Teflon PCB Overview
F4BMX-1/2 is a high-performance laminate crafted by layering imported varnished glass cloth with Teflon resin and Polytrtrafluoroethylene film. This product adheres to scientific formulations and stringent technological processes, offering superior electrical performance compared to the F4B series. It features a broader range of dielectric constants, lower dielectric loss tangent, increased resistance, and more stable performance. The use of imported woven glass fabric ensures consistency in the properties of the laminate.
F4BMX-1/2 Technical Specifications
Aspect
Meets the specification requirements for microwave PCB laminates according to national and military standards.
Types
- F4BMX217
- F4BMX220
- F4BMX245
- F4BMX255
- F4BMX265
- F4BMX275
- F4BMX285
- F4BMX294
- F4BMX300
Constanta dielectrică
- F4BMX217: 2.17
- F4BMX220: 2.20
- F4BMX245: 2.45
- F4BMX255: 2.55
- F4BMX265: 2.65
- F4BMX275: 2.75
- F4BMX285: 2.85
- F4BMX294: 2.94
- F4BMX300: 3.0
Dimensiuni (mm)
- Standard dimensions available: 300250, 380350, 440550, 500500, 460610, 600500, 840840, 8401200, 15001000, 18001000
- Customized dimensions are also available.
Grosime și toleranță (mm)
| Laminate Thickness | Toleranţă |
|---|---|
| 0.25 | ±0.025 |
| 0.5 | ± 0,05 |
| 0.8 | ± 0,05 |
| 1.0 | ± 0,05 |
| 1.5 | ±0.075 |
| 2.0 | ±0.09 |
| 3.0 | ±0.1 |
| 4.0 | ±0.1 |
| 5.0 | ±0.1 |
| 6.0 | ±0.12 |
| 8.0 | ±0.15 |
| 10.0 | ±0.18 |
| 12.0 | ±0.2 |
Note: The laminate thickness includes the copper thickness. Laminatele personalizate sunt disponibile pentru dimensiuni speciale.
Rezistență mecanică
| Grosime(mm) | Maximum Warp | Original Board | Single Side | Double Side |
|---|---|---|---|---|
| 0.25～0.5 | 0.030 | 0.050 | 0.025 | 0.020 |
| 0.8～1.0 | 0.025 | 0.030 | 0.020 | 0.020 |
| 1.5～2.0 | 0.020 | 0.025 | 0.015 | 0.015 |
| 3.0～5.0 | 0.015 | 0.020 | 0.010 | 0.010 |
Cutting/Punching Strength:
- For thickness <1mm, no burrs after cutting; minimum space between two punching holes is 0.55mm, Fără delaminare.
- For thickness >1mm, no burrs after cutting; minimum space between two punching holes is 1.10mm, Fără delaminare.
Coajă de rezistență (for 1oz copper):
- Normal state: ≥18N/cm; No bubble or delamination peel strength: ≥15N/cm (in constant humidity and temperature, and kept in molten solder at 260 degree Celsius±2 degree Celsius for 20 secunde).
Chemical Property
The chemical etching method for PCB can be used without altering the dielectric properties of the laminate. Plating through holes requires sodium treatment or plasma treatment. Hot Air Level temperature must not exceed 253 degrees Celsius and cannot be repeated.
Electrical Property
| Nume | Test Condition | Unitate | Value |
|---|---|---|---|
| Density | Normal state | g/cm³ | 2.1～2.35 |
| Moisture Absorption | Dip in distilled water at 20±2°C for 24 ore | % | ≤0.08 |
| Operating Temperature | High-low temperature chamber | grad Celsius | -50°C～+260°C |
| Conductivitate termică | W/m/k | 0.3~0.5 | |
| Cte | Typical (εr :2.1~2.3) | PPM/° C. | X: 24(x), Y: 34(y), Z.: 235(z) |
| Cte | Typical (εr :2.3~2.9) | PPM/° C. | X: 16(x), Y: 20(y), Z.: 168(z) |
| Cte | Typical (εr :2.9~3.38) | PPM/° C. | X: 12(x), Y: 15(y), Z.: 92(z) |
| Shrinkage Factor | 2 hours in boiling water | % | < 0.0002 |
| Rezistivitatea suprafeței | DC, 500V, Normal state | MΩ | ≥2*10^5 |
| Under constant humidity and temperature | ≥8*10^4 | ||
| Rezistivitatea volumului | Normal state | MΩ · cm | ≥8*10^6 |
| Under constant humidity and temperature | ≥2*10^5 | ||
| Surface dielectric strength | Normal state | d=1mm(Kv/mm) | ≥1.2 |
| Under constant humidity and temperature | ≥1.1 | ||
| Constanta dielectrică | 10GHz, εr | (±2%) | See table below |
| Factor de disipare | 10GHz tgδ | See table below |
Dielectric Constant and Dissipation Factor at 10GHz
| Tip | Constanta dielectrică (εr) | Factor de disipare (tgδ) |
|---|---|---|
| F4BMX217 | 2.17 | – |
| F4BMX220 | 2.20 | – |
| F4BMX245 | 2.45 | – |
| F4BMX255 | 2.55 | – |
| F4BMX265 | 2.65 | – |
| F4BMX275 | 2.75 | – |
| F4BMX285 | 2.85 | – |
| F4BMX294 | 2.94 | – |
| F4BMX300 | 3.0 | – |
