Product Overview
UGPCB’s 2+N+2 Countersink hole HDI 8L PCB with Blind Hole is a high-performance لوحة الدوائر المطبوعة designed for advanced electronic applications. هذا ثنائي الفينيل متعدد الكلور integrates high-density interconnect (مؤشر التنمية البشرية) technology with countersink holes and blind vias, offering superior reliability for intelligent digital products. With an 8-layer structure, it supports complex designs while maintaining a compact form factor, making it ideal for space-constrained devices. Key parameters include a 1.0mm finished thickness, FR-4 material, and immersion gold surface treatment, ensuring durability and efficient signal transmission.
Definition of the Product
This PCB is defined as an 8-layer HDI board featuring a 2+N+2 build-up structure, which refers to two sequential lamination cycles with a core layer (N). It incorporates countersink holes—conical recesses for screw heads—and blind vias that connect outer layers to inner layers without penetrating the entire board. This design enhances routing density and reduces size, catering to modern تصميم ثنائي الفينيل متعدد الكلور trends for high-speed applications.
Design Key Points
When designing this PCB, critical factors include minimizing trace and space to 3mil/3mil for high-density routing, and adhering to hole size specifications: mechanical holes at 0.2mm and laser-drilled blind holes at 0.1mm. The copper thickness (inner 1OZ, outer 0.5OZ) must balance current carrying capacity and signal integrity. Designers should prioritize thermal management and impedance control, especially for تجميع PCBA العمليات, to avoid issues like signal loss. Using HDI PCB design software is recommended to optimize layer stacking and via placement.
مبدأ العمل
The PCB operates by facilitating electrical connections between components through its layered structure. Blind holes allow interconnections between specific layers, reducing signal path length and improving speed, while countersink holes provide mechanical stability for mounting components. ال مؤشر التنمية البشرية technology enables shorter pathways, enhancing performance in high-frequency applications, such as those found in ثنائي الفينيل متعدد الكلور for smart devices.
Applications and Uses
This PCB is widely used in intelligent digital products, including smartphones, أقراص, الأجهزة القابلة للارتداء, and IoT equipment. Its high-density design supports advanced functionalities like 5G connectivity and AI processing, making it a top choice for PCB manufacturers focused on innovation. Applications extend to automotive electronics and medical devices where reliability is critical.
تصنيف
Based on structure, this product falls under the اتش دي اي ثنائي الفينيل متعدد الكلور category, specifically a 2+N+2 type with blind and buried vias. It can be classified by layer count (8ل), material (فر-4), and surface finish (immersion gold + OSP), aligning with industry standards for high-end PCBA solutions.
Materials Used
The primary material is فر-4, a flame-retardant epoxy laminate known for its excellent electrical insulation and mechanical strength. Copper foils (1OZ inner, 0.5OZ outer) provide conductivity, while the immersion gold surface treatment offers corrosion resistance and solderability, crucial for PCBA assembly. This material selection ensures the PCB meets RoHS compliance for environmental safety.
خصائص الأداء
Performance highlights include high thermal stability, low signal loss, and impedance control. With a minimum trace width of 3mil, it supports high-speed data transmission. The blind hole technology reduces parasitic capacitance, تحسين سلامة الإشارة. These features make it reliable for demanding PCB applications, such as in high-frequency digital products.
Structural Details
The structure consists of 8 layers with a symmetric build-up: two outer layers connected via blind vias to inner layers, surrounding a core. Countersink holes are machined on the surface for secure component mounting. This layout maximizes space efficiency and supports complex PCBA designs, such as those with BGA components.
الميزات الرئيسية
Key features include miniaturization capabilities, enhanced reliability due to robust via structures, and compatibility with lead-free soldering. The blue or white solder mask aids in inspection, while the 1.0mm thickness ensures durability. These attributes make it a preferred choice for PCB procurement in cutting-edge electronics.
Production Process
The manufacturing process comprises multiple stages: inner-layer imaging, lamination, laser drilling of blind vias, mechanical drilling of counterbore holes, plating, and surface finishing. Quality assurance involves electrical testing and automated optical inspection (الهيئة العربية للتصنيع) to ensure compliance with specifications. This workflow emphasizes precision in HDI PCB production, ensuring high manufacturing yield for subsequent PCBA integration.
Usage Scenarios
Common usage scenarios include consumer electronics like smart home devices, industrial automation systems, and communication hardware. It is ideal for applications requiring compact, high-speed PCBs, such as in PCBA for embedded systems or automotive control units. This versatility supports innovation in PCB-driven technologies.
